The Generalized Linear Model

Univariate Statistics and Methodology using R

Martin Corley

Psychology, PPLS

University of Edinburgh

Aliens

A Binary World

A Binary World

A Binary World

1,000 Aliens

id	quality	SPLATTED
The Great Odorjan of Erpod	84	0
Hapetox Bron	34	1
Loorn Molzeks	92	0
Ba'lite Adrflen	49	1
Tedlambo Garilltet	93	0
Goraveola Grellorm	5	1
Colonel Garqun	55	1
Bosgogo Lurcat	64	1
Osajed Voplily	45	0
Subcommander Edorop	90	0

• quality = quality of singing

• SPLATTED = whether splatted (1 or 0)

1,000 Aliens

1,000 Aliens

• using geom_jitter() with alpha=.5

Binomial Regression, Conceptually

• each alien either gets splatted or doesn’t

  • each observation is either a 1 or a 0

• underlyingly, there’s a binomial distribution

• for each value of “quality of singing” there’s a probability of getting splatted

• for each alien, the outcome is deterministic

• but it’s the probability we are ultimately interested in

• we can approximate it by binning our data…

Binned Data

singers <- singers |>
    mutate(bin = cut_interval(quality,
        10))

dat <- singers |>
    group_by(bin) |>
    summarise(prop = mean(SPLATTED))

dat

# A tibble: 10 × 2
   bin            prop
   <fct>         <dbl>
 1 [1,10.9]    0.982
 2 (10.9,20.8] 0.959
 3 (20.8,30.7] 0.935
 4 (30.7,40.6] 0.803
 5 (40.6,50.5] 0.573
 6 (50.5,60.4] 0.311
 7 (60.4,70.3] 0.115
 8 (70.3,80.2] 0.0388
 9 (80.2,90.1] 0.00893
10 (90.1,100]  0.0351

Binned Data

singers <- singers |>
    mutate(bin = cut_interval(quality,
        10))

dat <- singers |>
    group_by(bin) |>
    summarise(prop = mean(SPLATTED))

dat |>
    ggplot(aes(x = bin, y = prop)) +
    xlab("quality bin") +
    ylab("prop splatted") +
    geom_point(size = 3) +
    scale_x_discrete(label = 1:10)

Best Fit Lines

• we can fit our data using a standard linear model

• but there’s something very wrong…

The Problem with Probability

The Problem with Probability

• a linear model predicts impossible values because probability isn’t linear; it’s asymptotic

The Problem with Probability

• variance necessarily covaries with probability

Assumptions

Log Odds

Probability and Odds

\[\textrm{odds}(y)=\frac{p(y)}{1-p(y)}\]

\[0<p<1\] \[0<\textrm{odds}<\infty\]





\(p(y)\)

\(\textrm{odds}(y)\)





throw heads

\(\frac{1}{2}\)

\(\frac{1}{1}\)





throw 8 with two dice

\(\frac{5}{36}\)

\(\frac{5}{31}\)





get splatted

\(\frac{99}{100}\)

\(\frac{99}{1}\)



Probability and Odds



• odds never goes below zero

• odds rises to \(\infty\)

Refresher: (Natural) Logarithms

• a logarithm is the power you would raise a number to to obtain another number

\[10^3=1000; \log_{10}(1000)=3\]

log(1000, base = 10)

[1] 3

Refresher: (Natural) Logarithms

• a logarithm is the power you would raise a number to to obtain another number

\[10^3=1000; \log_{10}(1000)=3\]

• a natural logarithm is the power you would raise the number \(e\) to to obtain another number

\[e^{6.908}=1000; \log(1000) = 6.908\]

exp(6.908)

[1] 1000

log(1000)

[1] 6.908

Refresher 2

• what value does \(e\) have? (\(e^1=e\))

exp(1)

[1] "2.71828182845904509080"

Why \(e\)?

• \(\log(l)\) = area under curve between \(1\) and \(l\) (negative if \(l<1\))

log(3)

[1] 1.099

log(0.3)

[1] -1.204

Refresher 2

• what value does \(e\) have? (\(e^1=e\))

exp(1)

[1] "2.71828182845904509080"

• \((\textrm{any number})^0=1\)

log(1)

[1] 0

• \(\log(0)=-\infty\)

log(0)

[1] -Inf

• \(\log(\infty)=\infty\)

log(Inf)

[1] Inf

Probability and Log-Odds

• \(\log(0)=-\infty\); \(\log(\infty)=+\infty\); \(\log(1)=0\)
• log-odds of \(0\) (odds of \(1\)) are exactly 50:50 (\(p=0.5\))

• working left-to-right, log-odds of zero are equal to odds of one which are even-stevens or p=.5

Probability and Log-Odds

• if log-odds are less than zero, the odds go down (multiplied by <1)

• if log-odds are greater than zero, the odds go up (multiplied by >1)

• high odds = high probability

The Generalized Linear Model

The Generalized Linear Model

• generalises the linear model using mapping functions

• coefficients are in logit (log-odds) units



• coefficients use Wald’s \(z\) instead of \(t\)

• fit using maximum likelihood

Likelihood

The Generalized Linear Model

• generalises the linear model using mapping functions

• coefficients are in logit (log-odds) units



• coefficients use Wald’s \(z\) instead of \(t\)

• fit using maximum likelihood



• but actually it’s all quite straightforward…

Alien Singer Splat Probability

id	quality	SPLATTED
The Great Odorjan of Erpod	84	0
Hapetox Bron	34	1
Loorn Molzeks	92	0
Ba'lite Adrflen	49	1
Tedlambo Garilltet	93	0
Goraveola Grellorm	5	1
Colonel Garqun	55	1
Bosgogo Lurcat	64	1



• use glm() instead of lm()

• specify link function with family = binomial

mod.b <- glm(SPLATTED ~ quality,
    family = binomial, data = singers)

the DV can be a 2-level factor; family="binomial" (with quotes) also works

Evaluating the Model

anova(mod.b)

Analysis of Deviance Table

Model: binomial, link: logit

Response: SPLATTED

Terms added sequentially (first to last)

        Df Deviance Resid. Df Resid. Dev
NULL                      999       1377
quality  1      800       998        577

• NB., no statistical test done by default

• deviance compares the likelihood of the new model to that of the previous model

  • a generalisation of sums of squares

  • lower “residual deviance” is good (a bit like Residual Sums of Squares)

• deviance is similar to our notion of sums of squares that we used in linear models
• it is the likelihood of our model, compared to the null model (with no predictors)
• so lower residual deviance is kind of like less “misfit” of the model to the data

Evaluating the Model

        Df Deviance Resid. Df Resid. Dev
NULL                      999       1377
quality  1      800       998        577

• deviance is \(-2\times\) the log-likelihood ratio of the reduced compared to the full model
• higher deviance is good (a bit like \(F\))

mod.n <- glm(SPLATTED ~ 1, family = binomial, data = singers)
logLik(mod.n)

'log Lik.' -688.5 (df=1)

logLik(mod.b)

'log Lik.' -288.6 (df=2)

-2 * (logLik(mod.n) -
  logLik(mod.b))

'log Lik.' 799.8 (df=1)

• here, 799.8 is pretty much equal to the Deviance of 800 above

Evaluating the Model

• model deviance maps to the \(\chi^2\) distribution

• can specify a \(\chi^2\) test to statistically evaluate model in a similar way to \(F\) ratio

anova(mod.b, test = "Chisq")

Analysis of Deviance Table

Model: binomial, link: logit

Response: SPLATTED

Terms added sequentially (first to last)

        Df Deviance Resid. Df Resid. Dev Pr(>Chi)
NULL                      999       1377
quality  1      800       998        577   <2e-16 ***
---
Signif. codes:  0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1

• now when we consider deviance, we can actually test it against a chisquare distribution
• just like F was a ratio
• we’re now using a likelihood ratio
• and we can test using something like this - anova, test chisq

Model Coefficients

Call:
glm(formula = SPLATTED ~ quality, family = binomial, data = singers)

Coefficients:
            Estimate Std. Error z value Pr(>|z|)
(Intercept)  5.08191    0.33410    15.2   <2e-16 ***
quality     -0.10557    0.00642   -16.5   <2e-16 ***
---
Signif. codes:  0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1

(Dispersion parameter for binomial family taken to be 1)

    Null deviance: 1377.06  on 999  degrees of freedom
Residual deviance:  577.29  on 998  degrees of freedom
AIC: 581.3

Number of Fisher Scoring iterations: 6

Model Coefficients

coefficients are in logits (= log-odds)

...
            Estimate Std. Error z value Pr(>|z|)
(Intercept)  5.08191    0.33410    15.2   <2e-16 ***
quality     -0.10557    0.00642   -16.5   <2e-16 ***
...

• zero = “50/50” (odds of 1)

• value below zero: probability of being splatted decreases as quality increases

Log-Odds, Odds, and Probability

...
            Estimate Std. Error z value Pr(>|z|)
(Intercept)  5.08191    0.33410    15.2   <2e-16 ***
quality     -0.10557    0.00642   -16.5   <2e-16 ***
...

a calculation for quality = 50

• log-odds: \(5.08+-0.11\cdot50=\color{red}{-0.42}\)

• odds: \(e^{-0.42}=\color{red}{0.657}\)

• probability: \(\frac{0.657}{1+0.657}=\color{red}{0.3965}\)

\[\hat{y}_i=b_0+b_1x_i\] \[\textrm{odds}=e^{\hat{y}_i}\] \[p=\frac{\textrm{odds}}{1+\textrm{odds}}\]

• well, can convert them back, at least some of the way

• exponent is the opposite of logarithm

• so for a singer who has quality of singing 50

• their log-odds of splatted are the intercept + the coef * 50

• we can exponentiate that, to get their odds

• and we can then convert that back to probability

• note we can do this for a single predicted value, but how do we talk about “the association”.

  • every 1 quality decreases log-odds by -0.11
  • go up 1 qual, you add that amount onto your log odds
  • this isn’t true of odds

A Useful Function

• intuitive to think in probability

• useful to write a function which takes a value in logits l and converts it to a probability p

l2p <- function(logits) {
  odds <- exp(logits)
  prob <- odds/(1 + odds)
  return(prob)
}

• qualities 50 and 51

l2p(5.08+-0.11*50)

[1] 0.3965

l2p(5.08+-0.11*51)

[1] 0.3705

• qualities 70 and 71

l2p(5.08+-0.11*70)

[1] 0.06786

l2p(5.08+-0.11*71)

[1] 0.06123

• for 50 and 51, changes are in the second digit; for 70 and 71, they’re in the 3rd digit

Representing the Model Graphically

singers |>
  ggplot(aes(x = quality, y = SPLATTED)) +
  ylab("p(SPLATTED)") +
  geom_jitter(size = 3, width = 0, height = 0.2, alpha = 0.1) +
  geom_smooth(method = "glm", method.args = list(family = binomial)) +
  scale_y_continuous(breaks = seq(0, 1, by = 0.2))

• note the scale_y_continuous which ensures the y axis doesn’t show silly values

One Last Trick

• so far we’ve looked at

  • model deviance and \(\chi^2\) (similar to sums of squares and \(F\))

  • model coefficients and how to map them to probability

• what about “explained variance” (similar to \(R^2\))?

• no really good way of doing this, many proposals

• SPSS uses something called “accuracy” (how well does the model predict actual data?)

• not very informative, but good for learning R

Accuracy

• first, what does the model predict (in logit units)?

guess <- predict(mod.b)  # in logit units

• if the chance of being splatted is more than .5 (logit > 0) call it a “splat”

guess <- ifelse(guess > 0, 1, 0)

• how well do predicted splats match actual splats?

hits <- sum(guess == singers$SPLATTED)
hits/length(singers$SPLATTED)

[1] 0.879

• present model “correctly predicts” 87.9% of the observations

Other Types of Data

• logit regression is one type of GLM

• others make use of different link functions (through family=...)



• poisson: number of events in a time period

• inverse gaussian: time to reach some criterion

• …

GLMs

Predictor Variables

• linear

• convertible to linear (use log() etc.)

• non-convertible (use contrasts() etc. to map)

• don’t affect the choice of model



Dependent Variables

• linear

• convertible to linear (use log() etc.)

• non-convertible (use glm() with family=...)

• directly affect the choice of model

End
