Nominal Data

Univariate Statistics and Methodology using R

Martin Corley

Psychology, PPLS

University of Edinburgh

Binomial Test

Last Week

• the \(t\)-test and \(z\)-test deal with interval (at least) data

• they can compare continuous data to a distribution with

  • known \(\mu\) and \(\sigma\) (\(z\)-test)
  • known \(\mu\) and unknown \(\sigma\) (one-sample \(t\)-test)

• they can compare continuous data from two samples
  • independent groups (independent-samples \(t\)-test)
  • related groups (paired-samples \(t\)-test)

• these are formalisations of what we talked about last week

• the one-sample and related-samples \(t\)-tests use essentially the same maths

Not Everything is Numbers

• sometimes the things we are interested in aren’t numeric

• fashionable or not?

• heads or tails?

• USMR student or not?

Binomial Distribution

• two possible outcomes with fixed probabilities \(p\) and \(1-p\)

• with enough trials, proportion of outcomes will be \(p\) and \(1-p\)

• the number of trials (\(n\)) is fixed
• each observation is independent
• each observation has one of two outcomes
• the probability of each outcome is consistent

Binomial?

• a fair coin is tossed 20 times
  • \(x\) = # of heads
• draw 3 cards at random without replacement
  • \(x\) = # of diamonds
• draw 3 cards at random with replacement
  • \(x\) = # of diamonds
• the probability of having blood type B is .1; choose 4 people at random.
  • \(x\) = # with type B

Binomial Distribution

• toss a coin 100 times
• how many “successes” (=heads, say) are you likely to get?

Binomial Test

• if you toss a coin 4 times, what’s the probability of it landing on heads at least 3 times?

• \(2^4 = 16\) possible sequences of outcomes

• Of those 16, 5 outcomes include \(\ge\) 3 heads

• \(p = 5/16 = .3125\)

Toss1	Toss2	Toss3	Toss4	HEADS
H	H	H	H	4
T	H	H	H	3
H	T	H	H	3
T	T	H	H	2
H	H	T	H	3
T	H	T	H	2
H	T	T	H	2
T	T	T	H	1
H	H	H	T	3
T	H	H	T	2
H	T	H	T	2
T	T	H	T	1
H	H	T	T	2
T	H	T	T	1
H	T	T	T	1
T	T	T	T	0

Binomial Test

print(
  binom.test(3, 4, p = 0.5, alternative = "greater"),
  digits = 7
)

    Exact binomial test

data:  3 and 4
number of successes = 3, number of trials = 4, p-value = 0.3125
alternative hypothesis: true probability of success is greater than 0.5
95 percent confidence interval:
 0.2486046 1.0000000
sample estimates:
probability of success
                  0.75

• don’t be fooled by the probability of success which is just 3/4

Binomial Test (2)

approximately 9% of the world’s population have blue eyes; is the USMR class of 2022–23 a representative sample?

Eye Colours for USMR

(eyes <- table(usmrEyes))

usmrEyes
 blue brown green  grey hazel other
   18    43     7     1     8     3

putting (eyes <- ...) in parentheses assigns and prints at the same time

Binomial Test

• approximately 9% of the world’s population have blue eyes

binom.test(
  eyes["blue"], sum(eyes),
  0.09, alternative = "two.sided"
)

    Exact binomial test

data:  eyes["blue"] and sum(eyes)
number of successes = 18, number of trials = 80, p-value = 0.0002
alternative hypothesis: true probability of success is not equal to 0.09
95 percent confidence interval:
 0.1391 0.3321
sample estimates:
probability of success
                 0.225

THe \(\chi^2\) Distribution

Goodness-of-Fit Test

• so what happens when we are interested in more than two outcomes?

• we have already talked about dice “numbers” being categories

• we know that, in a fair die, the probability of getting each number is \(\frac{1}{6}\) (H₀)

• can we assess the probability of getting a known set of throws if H₀ is true?

• if the probability is low enough (\(p<.05\)) we can assert that the die is biased

Calculating \(\chi^2\)

• let’s assume we throw the die 600 times

• if everything worked out perfectly for an unbiased die, our expected values would be:

(expected <- 600 * c(1/6, 1/6, 1/6, 1/6, 1/6, 1/6))

[1] 100 100 100 100 100 100

• and we can calculate a \(\chi^2\) statistic using the formula

\[\chi^2 = \sum{\frac{(O_i-E_i)^2}{E_i}}\] where \(O_i\) is the \(i\textrm{th}\) observed and \(E_i\) is the \(i\textrm{th}\) expected value

Calculating \(\chi^2\)

• we don’t have to do this calculation by hand

• we can do it piece-by-piece, starting with 600 throws I’ve ‘recorded’

throws

6 3 3 3 1 5 4 6 4 6 2 4 6 6 2 6 1 5 6 1 4 6 4 2 1 1 1 4 1 3 2 3 3 6 1 1 6 6 6 2 3 1 2 6 1 5 3 6 3 5 1 5 1 4 4 3 3 1 3 6 2 4 5 3 4 4 2 5 5 6 3 2 2 6 6 3 1 2 1 6 ...

table(throws)

throws
  1   2   3   4   5   6
 92 124 102  96  77 109

Calculating \(\chi^2\)

chiTab <- data.frame(
  expected=expected, # from earlier calculation
  observed=table(throws) |> as.integer()
)
chiTab

  expected observed
1      100       92
2      100      124
3      100      102
4      100       96
5      100       77
6      100      109

\[\chi^2 = \sum{\frac{(O_i-E_i)^2}{E_i}}\]

as_integer() chucks out irrelevant information from the table of throws, leaving the counts

Calculating \(\chi^2\)

chiTab <- chiTab |>
    mutate(sq_diff = (observed - expected)^2)

\[\chi^2 = \sum{\frac{\color{red}{(O_i-E_i)^2}}{E_i}}\]

using the tidyverse way of doing things, where mutate() creates columns

Calculating \(\chi^2\)

chiTab <- chiTab |>
    mutate(sq_diff = (observed - expected)^2,
        std_sq_diff = (sq_diff/expected))

\[\chi^2 = \sum{\color{red}{\frac{(O_i-E_i)^2}{E_i}}}\]

using the tidyverse way of doing things, where mutate() creates columns

Calculating \(\chi^2\)

chiTab <- chiTab |>
    mutate(sq_diff = (observed - expected)^2,
        std_sq_diff = (sq_diff/expected))
chiTab

\[\chi^2 = \sum{\color{red}{\frac{(O_i-E_i)^2}{E_i}}}\]

using the tidyverse way of doing things, where mutate() creates columns

Calculating \(\chi^2\)

chiTab <- chiTab |>
    mutate(sq_diff = (observed - expected)^2,
        std_sq_diff = (sq_diff/expected))
chiTab

  expected observed sq_diff std_sq_diff
1      100       92      64        0.64
2      100      124     576        5.76
3      100      102       4        0.04
4      100       96      16        0.16
5      100       77     529        5.29
6      100      109      81        0.81

sum(chiTab$std_sq_diff)

[1] 12.7

• df = \(\textrm{number of groups}-1 = 5\)

\[\chi^2 = \sum{\color{red}{\frac{(O_i-E_i)^2}{E_i}}}\]

\[\chi^2 = \color{red}{\sum{\frac{(O_i-E_i)^2}{E_i}}}\]

using the tidyverse way of doing things, where mutate() creates columns

Evaluating \(\chi^2\)

• so for the particular random throws we did, \(\chi^2=12.7\)

• what we want to know is how probable that value is in a world where chance governs dice throws

• we already know two important things

  1. we’re going to have to work out the distribution of \(\chi^2\) and work out the probability of getting that value or more

  2. the reason we’re calling the value we’ve calculated \(\chi^2\) is because we’re going to compare it to the \(\chi^2\) distribution

Why do Things the Easy Way?

• calculate and plot 10,000 random 600-fair-dice-throw \(\chi^2\)s

diceChi <- function(n) {
    dice <- sample(1:6, n,
        replace = TRUE)
    chisq.test(table(dice))$statistic
}

chiDist <- replicate(10000,
    diceChi(600))

plot(density(chiDist), main = "chisq(5)",
    lwd = 2)

for more on chisq.test(...)$statistic, start with str(chisq.test(...))

The \(\chi^2\) Distribution

the “squared” in \(\chi^2\) is because \(\chi^2\) is derived from squared normal distributions

\(\chi^2\) Probability

• for our random 600 dice throws a couple of slides back

  • \(\chi^2=12.7\), \(\textrm{df} = 5\)

• we can use pchisq()

pchisq(12.7, 5, lower.tail=FALSE)

[1] 0.02636

• looks like we can conclude that our die is unlikely to be fair

Two-Dimensional \(\chi^2\)

Types of \(\chi^2\) Test

• what we’ve just seen is a goodness of fit calculation

  • do the data come from a specific distribution?

• test of homogeneity

  • do groups have same distribution of a variable of interest?

• test of independence

  • are categorical variables associated with each other?

course	Elsewhere	UK
dapr1	9	49
dapr2	5	21
rms2	9	29
usmr	17	27

Where are You From?

• data from all of the stats modules in Psychology

statsClasses |>
    select(course, in_uk) |>
    table()

       in_uk
course  Elsewhere UK
  dapr1         9 49
  dapr2         5 21
  rms2          9 29
  usmr         17 27

statsClasses |>
    select(course, in_uk) |>
    table() |>
    addmargins()

       in_uk
course  Elsewhere  UK Sum
  dapr1         9  49  58
  dapr2         5  21  26
  rms2          9  29  38
  usmr         17  27  44
  Sum          40 126 166

• contingency tables

in the second version, I’ve added the addmargins() function to give useful summary statistics. I can also use functions like rowSums() which I’ll show you in the next slide

Under the Null Hypothesis

• students on each module would be equally likely to come from the UK

• in other words, of the 58 students on dapr1, \(\frac{126}{166}\times{}58\), or approx 44.02 students, should come from the UK under H₀

       in_uk
course  Elsewhere  UK Sum
  dapr1         9  49  58
  dapr2         5  21  26
  rms2          9  29  38
  usmr         17  27  44
  Sum          40 126 166

• we can repeat this calculation for each cell of the table, to give “expected values”

  • like the probability-based values for dice

Expected Values

• repeating the calculation is easy using the “outer product (\(\otimes\))” operator %o% in R (this takes two vectors and multiplies them out into a matrix)

\[ (a,b) \otimes (y, z) = \begin{bmatrix} a \times y & b \times y \\ a \times z & b \times z \\ \end{bmatrix} \]

Expected Values

• repeating the calculation is easy using the “outer product (\(\otimes\))” operator %o% in R (this takes two vectors and multiplies them out into a matrix)

t <- statsClasses |>
  select(course, in_uk) |>
  table()
t

       in_uk
course  Elsewhere UK
  dapr1         9 49
  dapr2         5 21
  rms2          9 29
  usmr         17 27

# expected values
e <- rowSums(t) %o%
  colSums(t)/sum(t)
e

      Elsewhere    UK
dapr1    13.976 44.02
dapr2     6.265 19.73
rms2      9.157 28.84
usmr     10.602 33.40

Restating the Null Hypothesis

• under H₀:

  • knowing which class people are in gives no additional information about where they come from

  • knowing where they’re from gives no additional information about which class they’re in

observed

       in_uk
course  Elsewhere UK
  dapr1         9 49
  dapr2         5 21
  rms2          9 29
  usmr         17 27

expected

      Elsewhere    UK
dapr1    13.976 44.02
dapr2     6.265 19.73
rms2      9.157 28.84
usmr     10.602 33.40

Using plot()

plot(t)

plot(as.table(e))

e was created as a matrix (using %o%) so here we tell R to treat it as a table

Are The Courses Different?

chisq.test(t)

    Pearson's Chi-squared test

data:  t
X-squared = 7.8, df = 3, p-value = 0.05

• might need to look more closely

chisq.test(t)$p.value

[1] 0.05124

Bonus: Eye Colours

• are USMR eyes different from estimated world proportions?

chisq.test(
  table(uc),
  p = c(0.09, 0.75, 0.02, 0.03, 0.05, 0.06)
)

    Chi-squared test for given probabilities

data:  table(uc)
X-squared = 160, df = 5, p-value <2e-16

Bonus: Eye Colours

• are eye colours different between stats classes?

chisq.test(table(ec))

    Pearson's Chi-squared test

data:  table(ec)
X-squared = 34, df = 18, p-value = 0.01
